Shining 3D Freescan Combo

SHINING 3D FreeScan Combo – Professional 3D Scanner for Reverse Engineering, Metrology and Industrial Inspection

The SHINING 3D FreeScan Combo is a high-precision, metrology-grade 3D scanner designed for professional applications in reverse engineering, quality control, product development, manufacturing, and industrial inspection. Combining advanced blue laser technology with infrared light scanning, the FreeScan Combo delivers exceptional accuracy, flexibility, and efficiency for capturing complex geometries across a wide range of industries.

With certified accuracy of up to 0.02 mm, an ergonomic handheld design, and multiple scanning modes, the FreeScan Combo is an ideal solution for engineers, designers, manufacturers, and research institutions seeking reliable and highly detailed 3D measurement data.

Why Choose the FreeScan Combo?

The FreeScan Combo is engineered to deliver professional-grade results while remaining lightweight, portable, and easy to use. Its dual-light technology enables accurate scanning of various object sizes, shapes, and surface conditions.

• Metrology-grade accuracy: Up to 0.02 mm precision
• Dual light source: Blue laser and infrared scanning technology
• Lightweight design: Only 620 g for comfortable operation
• High-speed scanning: Up to 3.6 million points per second
• Markerless scanning: Fast infrared scanning for feature-rich objects

Advanced 3D Scanning Technology

The FreeScan Combo integrates multiple scanning modes into a single compact device, providing maximum flexibility for different workflows and object types.

• Multiple-line mode: Fast scanning of large surfaces and components
• Fine-detail mode: Capture intricate features and complex geometries
• Deep-hole mode: Ideal for pockets, cavities, and hard-to-reach areas
• Infrared mode: Marker-free scanning for efficient data acquisition

Technical Highlights

• Accuracy: Up to 0.02 mm
• Volumetric Accuracy: 0.02 + 0.033 mm/m
• Scanning Speed: Up to 3,600,000 points per second
• Maximum Field of View: Up to 600 × 600 mm
• Point Distance: 0.05–10 mm
• Weight: 620 g
• Certifications: VDI/VDE 2634, ISO 10360, CE, FCC, RoHS

Applications

• Reverse Engineering
• Quality Inspection and Quality Control
• Product Design and Development
• Manufacturing and Production Verification
• Automotive Engineering
• Industrial Equipment and Machinery
• Tool and Mold Manufacturing
• Research and Development
• Digital Archiving and Documentation

Ideal for Reverse Engineering

The FreeScan Combo enables users to quickly digitize existing components and transform them into accurate CAD-ready models. This makes it an excellent solution for recreating legacy parts, improving existing designs, optimizing manufacturing processes, and accelerating product development workflows.

Powerful Software Included

The scanner is powered by FreeScan Software, a professional platform designed to streamline the entire scanning workflow, from calibration and data acquisition to mesh optimization and export.

• AI-powered data cleanup and optimization
• Step-by-step scanning guidance
• Adjustable scanning resolution
• Multiple scanning workflows
• No subscription fees or hidden software costs

Compatible with Leading Engineering Software

FreeScan Combo integrates seamlessly with industry-standard software for inspection, reverse engineering, and CAD modeling.

• Geomagic Design X
• Geomagic Control X
• PolyWorks
• EXModel Pro
• SHINING3D Inspect

Key Benefits

• Certified industrial-grade accuracy
• Fast and efficient data capture
• Compact and ergonomic handheld design
• Suitable for complex and challenging geometries
• Blue laser technology for highly accurate measurements
• Infrared scanning for fast marker-free workflows
• Professional solution for engineering, manufacturing, and inspection

Precision 3D Scanning for Modern Industry

The SHINING 3D FreeScan Combo combines speed, accuracy, and versatility in a single professional handheld scanner. Whether used for inspection, reverse engineering, digital manufacturing, or product development, it provides the reliable 3D measurement data required for today's most demanding industrial applications.
